Joyo JF24 Orthros Line Selector Pedal for Guitar Effects Pedals
$74.95
Postage
We offer free shipping Australia wide. Same day dispatch cut-off at 12pm, exclusive weekends& public holidays. Express shipping service available at additional cost.
Shop with Confidence
60 Day Money Back Guaranty T&Cs applied READ MORE /policies/refund-policy
The Joyo JF24 Orthros is a versatile multi-mode line selector pedal designed to simplify and expand your guitar setup. Effortlessly route effects pedals in parallel or series to maintain clean, uncoloured signals, and control multiple pedals with a single footswitch—eliminating the need for constant tap-dancing on your board.
Choose from multiple switching modes, including A/B, A/Bypass, B/Bypass, A/B/Bypass, A+B/Bypass, or A/B/Out Select using the A/B send and return. Independent level controls for both channels let you adjust volumes when switching between pedals, amps, or even guitars, giving you precise control over your rig. With the Orthros, you can focus on your performance and engage your audience, not your feet.
Specifications:
- Brand: Joyo
- Model: JF24 Orthros
- Dimensions: 120mm (L) × 97mm (W) × 55mm (H)
- Input: 1/4" Mono Audio Jack (Impedance 1MΩ)
- Output: 1/4" Mono Audio Jack (Impedance 1KΩ)
- Return A: 1/4" Mono Audio Jack (Impedance 1MΩ)
- Send A: 1/4" Mono Audio Jack (Impedance 1KΩ)
- Return B: 1/4" Mono Audio Jack (Impedance 1MΩ)
- Send B: 1/4" Mono Audio Jack (Impedance 1KΩ)
- Power Consumption: 22 mA
- Power: 9V DC Centre Negative (Not Included) or 9V Battery
